Body
Body: CAF
Total length (mm): 28,500
Width (mm): 2,400
Height (mm): 3,620
Capacity (6 passengers/m²): 205 (+16) | 40 seated (+16) + 165 standing + 1 driver
Number of articulations: 4
Tare weight (kg): 37,320
Doors
Doors: IFE
Number x Usable width (mm): 4x1,300
Type: Exterior sliding tilt
Control: Electromechanical
Braking
Braking: HANNING & KAHL
Motor/carrying bogies
Motor/carrying bogies: CAF
Quantity 2 / 1
Gauge (mm) 900
Traction motors
Type: Traktionssysteme Austria TMR 36-18-4
Number of poles: 4
Number of units: 8
Power [kW]: 70
Weight [kg]: 305
Maximum rotation [RPM]: 4527
Insulation class: IP54
Ventilation: Forced
Power Supply
Power Supply: Overhead Contact Line
Power Electronics
Power Electronics: CAF PA
Speed control: Voltage inverter (IGBT)
Integrated Onboard Information System
Integrated Onboard Information System: IBIS
Residual travel recorder: HASLER
Ticket vending machine: CARD4B
Auxiliary Equipment
Air conditioners: Electropneumatic control
Auxiliary circuit power supply: Static converter + Batteries
Batteries: Nickel/Cadmium
Air Conditioning
Air Conditioning: HISPACOLD
Static Converter
Static Converter: CAF PA
Performance
Maximum speed (km/h): 70
